¡á Water Filter for Wire-cut EDM


Ref. No. Size (mm) Filtering type Application Refer
W-02 150 X 33 X 350 External Japax-LS250/350...1000 SERIES
Seibu-EW250/300¡¦1000. EW-A5S AW400-3. EWP series
Sodick-330/453/654W. AW330/453. G3A. EPOC3W/3WS. EPOC series
W-17 260 X 29 X 340 External Mitsubishi DWC-N series
W-20 300 X 29 X 500 Internal Mitsubishi DWC-F.G.H.U.PH.HA DWC-70/90/110/200
W-20N 300 X 58 X 500 IN / EX with nipple Makino With nipple
IN / EX Mitsubishi DWC-B.SB.Z.SZ.SZ.P.A.SA.PA
W-23 260 X 46 X 280 External Makino-ec-3025/3040/3141/7050 series
Japax-JL65/85 series
W-23F 260 X 36 X 280 External Sodick-A350. A500. EPOC. AW. AP series
W-250A 300 X 29 X 250 Internal Mitsubishi Center
W-250AK 300 X 250 Internal with nipple Mitsubishi
W-25A 340 X 46 X 300 IN / EX Fanuc-Alpha series Center
Sodick-A320/350/500/530/600/750/280L
W-25A(N) 340 X 46 X 300 Internal with nipple Mitsubishi
W-25A(N)F 340 X 46 X 300   Fanuc Wih nipple
W-26 300 X 46 X 340 Internal Hitachi
W-28 150 X 32 X 370 IN / EX Agie series ¡¡
Charmilles-Robofil series
W-35 340 X 46 X 300 Internal Fanuc.Sodick
W-40 340 X 46 X 450 Internal Fanuc.Sodick
W-40S 340 X 46 X 450 Internal Sodick
W-41 300 X 29 X 250 IN / EX Mitsubishi-C1. C2. SX series
W-43 340 X 46 X 300 IN / EX Mitsubishi CX20.FX10/20/30. FX-K With nipple
W-45 300 X 29 X 300 IN / EX Mitsubishi B. Z. SZ. P. A. DWC-110PA With nipple
W-500A 300 X 29 X 500
W-500AK 300 X 500
W-H15190/16 150 X 33 X 370 External Agie-Agiecut, DEM etc¡¦
Charmilles-Robofil series
W-ONA 150 x 54 x 228   ONA
W-11 240 X 46 X 400   Brother


¡á Oil Filter for Die-sinking EDM

Ref. No. Description Filtering type Application Refer
E-04 150 X 33 X 450 External Charmilles
E-08 260 X 36 X 280 External Sodick
E-09 260 X 46 X 280 External Makino
E-10 260 X 36 X 340 External Hitachi
E-12 150 X 72 X 450 External Japax.Sodick
E-16 260 X 29 X 340 External Mitsubishi-DK. DM. DX. DP-431
E-18 150 X 35 X 350 Internal Mitsubishi-20. 25. 25C2. 25C3. 25C5. 25C6
E-24 260 X 29 X 340 Internal Mitsubishi-M. J. V series.DP-431
E-28 150 X 32 X 340 External Charmilles-Roboform series
E-36 300 X 58 X 500 IN / EX Mitsubishi-K. KS. S. W series
E-42 300 X 46 X 330 IN / EX EX. VXseries
E-60 185 X 46 X 450   Jinyoung
E-61 128 X 18 X 545
E-62 200 X 50 X 380
E-64 150 X 50 X 540
E-66 239 X 25 X 545
FL-5 150 X 33 X 360   Agie. Charmilles. Maho Layer filter
